EPOMAKER EK21 VIA Gasket Number Pad Instruction Manual

1. Utangulizi

The EPOMAKER EK21 VIA Gasket Number Pad is a versatile and highly functional numeric keypad designed for professionals and gamers. It features a 20-key layout, a premium aluminum alloy knob, and offers triple connectivity modes (Wired, Bluetooth, 2.4GHz Wireless). This manual provides detailed instructions for setup, operation, customization, and maintenance to ensure optimal performance and user experience.

2. Yaliyomo kwenye Kifurushi

Tafadhali thibitisha kuwa vipengee vyote vipo kwenye kifurushi chako:

• 1x EPOMAKER EK21 20% Number Pad
• 1x 2-in-1 Keycap-and-Switch Puller
• 1x Extra “Back” Keycap
• 1x 1.8m Detachable USB A-to-C Braided Cable
• 1x 2.4GHz Wireless Dongle
• 1x Mwongozo wa Mtumiaji (hati hii)

3. Bidhaa Imeishaview

The EK21 features a compact and ergonomic design with a multi-functional aluminum alloy knob and customizable RGB lighting. It is built with a gasket structure for a cushioned typing experience and hot-swappable PCB for easy switch replacement.

4. Mipangilio na Muunganisho

The EK21 offers three modes of connection: Wired, Bluetooth, and 2.4GHz Wireless.

4.1. Muunganisho wa Waya (USB-C)

1. Locate the USB-C port on the EK21.
2. Connect the provided USB A-to-C braided cable to the number pad and your computer.
3. The number pad will be automatically recognized and ready for use.

4.2. Muunganisho Usiotumia Waya wa 2.4GHz

1. Locate the 2.4GHz wireless dongle in the package.
2. Chomeka dongle kwenye mlango wa USB unaopatikana kwenye kompyuta yako.
3. Switch the mode selector on the EK21 to 2.4GHz wireless mode. The number pad will connect automatically.

4.3. Muunganisho wa Bluetooth 5.0

1. Switch the mode selector on the EK21 to Bluetooth mode.
2. On your device (computer, tablet, or smartphone), enable Bluetooth and search for new devices.
3. Select "EPOMAKER EK21" from the list of available devices to pair.

5. Maagizo ya Uendeshaji

5.1. Kazi Muhimu za Msingi

The EK21 features a standard numeric keypad layout with additional function keys for enhanced productivity.

• Funguo za Nambari (0-9): Standard number input.
• Operators (+, -, *, /): Basic arithmetic operations.
• Ingiza: Confirms input or moves to the next line.
• Nambari ya Kufuli: Toggles numeric keypad functionality.
• Esc: Escape function.
• Kichupo: Tab function.
• Fn: Function key for secondary key commands.

5.2. Multi-functional Aluminum Alloy Knob

The knob on the EK21 provides intuitive control over various functions:

• Rotate Clockwise/Counter-clockwise: Default for volume adjustment (Volume + / Volume -).
• Bonyeza: Default for Mute/Unmute audio.
• Customizable via VIA software for other functions.

5.3. Udhibiti wa Taa ya RGB

The EK21 features dynamic RGB backlighting. Use the following key combinations for on-device control:

• Fn + . (Period): Check battery level.
• Fn + Ingiza: Toggle backlight effect.
• Fn + - (Minus): Rekebisha mwangaza wa taa ya nyuma.

5.4. VIA Software Customization

The EK21 is fully programmable via VIA software, allowing for extensive customization of key assignments, macros, and lighting effects. To get started:

1. Download the VIA software from the official webtovuti.
2. Download the specific EK21 JSON file from the EPOMAKER webtovuti. Hii file is necessary for VIA to recognize and configure your EK21.
3. Open VIA software, load the EK21 JSON file, and connect your number pad.
4. You can now remap keys, create complex macros, configure multiple layers, and fine-tune RGB lighting to suit your workflow.

6. Usimamizi wa Betri

The EK21 is equipped with a 1000mAh battery for extended wireless usage.

• Inachaji: Connect the number pad via the USB-C cable to a power source (computer USB port or wall adapter). The RGB lighting may indicate charging status.
• Ukaguzi wa Betri: Bonyeza Fn + . (Period) to display the current battery level via the RGB lighting.

7. Matengenezo

7.1. Hot-Swappable Switches and Keycaps

The EK21 features a hot-swappable PCB, allowing you to easily change mechanical switches without soldering. The keycaps are also removable for customization or cleaning.

1. Use the provided 2-in-1 keycap-and-switch puller.
2. To remove a keycap, gently pull it upwards with the keycap puller.
3. To remove a switch, use the switch puller to grip the top and bottom clips of the switch and pull upwards.
4. To install a new switch, align its pins with the holes on the PCB and press down firmly until it clicks into place. Ensure pins are straight to avoid bending.
5. To install a new keycap, align it with the switch stem and press down.

7.2. Kusafisha

• Disconnect the number pad from all power sources before cleaning.
• Use a soft, dry cloth to wipe the surface of the number pad.
• For deeper cleaning, remove keycaps and use compressed air to clear debris from between switches.

8. Utatuzi wa shida

• Number Pad Not Responding:
  • Ensure the number pad is properly connected (wired) or paired (wireless/Bluetooth).
  • Angalia kiwango cha betri na chaji ikiwa ni lazima.
  • Try switching between connectivity modes.
• VIA Software Not Detecting EK21:
  • Ensure the EK21 is connected via USB-C.
  • Verify that the correct EK21 JSON file has been loaded into the VIA software.
  • Some users have reported needing a firmware update for VIA compatibility. Check the EPOMAKER support page for the latest firmware and instructions.
• Masuala ya Taa ya RGB:
  • Rekebisha mwangaza kwa kutumia Fn + - (Minus).
  • Toggle effects using Fn + Ingiza.
  • Customize lighting further using VIA software.
• Maisha duni ya Betri:
  • Punguza mwangaza wa RGB au zima taa wakati haihitajiki.
  • Ensure the number pad is fully charged.

9. Maelezo ya kiufundi

10. Rasilimali za Ziada

11. Udhamini na Msaada

EPOMAKER products come with a standard warranty. For specific warranty details, technical support, or further assistance, please visit the official EPOMAKER webtovuti au wasiliana na huduma kwa wateja wao. Hifadhi risiti yako ya ununuzi kwa madai ya udhamini.
