1. Utangulizi
This manual provides detailed instructions for the installation, programming, and operation of your Orbit 2-Outlet Programmable Hose Faucet Timer, Model 24621. This device is designed to automate your watering schedule, ensuring efficient irrigation for your garden or lawn. Please read these instructions carefully before use to ensure proper function and longevity of the product.
2. Bidhaa Imeishaview
The Orbit 2-Outlet Programmable Hose Faucet Timer features a large digital display and intuitive controls for easy programming. It allows for independent programming of two watering zones from a single faucet.
Picha ya 2.1: Mbele view of the Orbit 2-Outlet Programmable Hose Faucet Timer, displaying the digital screen and control dial.
Sifa Muhimu:
- Vituo viwili: Control two separate watering zones independently.
- Upangaji Rahisi: Simple interface with a large, easy-to-read digital display.
- Ratiba Zinazonyumbulika: Program watering intervals from every hour up to every 7th day.
- Adjustable Duration: Set watering times from 1 to 360 minutes.
- Kuchelewa kwa Mvua: Pause your watering schedule for 1 to 7 days.
- Uendeshaji wa Mwongozo: Instant faucet use without interrupting programmed schedules.
- Inayotumia Betri: Operates on batteries for convenience.
3. Ufungaji
3.1. Ufungaji wa Betri
- Tafuta sehemu ya betri nyuma ya kipima muda.
- Ondoa kifuniko cha betri.
- Insert two fresh AA alkaline batteries, ensuring correct polarity (+/-).
- Badilisha kifuniko cha betri kwa usalama.
3.2. Attaching the Timer to the Faucet
- Ensure the faucet is turned off.
- Thread the timer's inlet collar onto your outdoor hose faucet. Hand-tighten only; do not use tools.
- Connect your garden hoses to the two outlets at the bottom of the timer. Hand-tighten only.
- Slowly turn on the faucet completely.
Picha ya 3.1: The timer connected to a water faucet with two hoses attached, ready for use in a garden setting.
4. Maagizo ya Kuandaa
The timer features a large dial and buttons for easy navigation through programming steps. Use the KITUO button to select which outlet (1 or 2) you are programming.
4.1. Weka Saa
- Washa piga kuwa WEKA SAA.
- Tumia < na > buttons to adjust the current time.
- Bonyeza kwa OK kitufe cha kuthibitisha.
4.2. Weka Muda wa Kuanza
- Washa piga kuwa KUANZA MUDA.
- Tumia < na > buttons to set your desired watering start time.
- Bonyeza OK kuthibitisha.
4.3. Set Watering Duration (How Long)
- Washa piga kuwa MUDA GANI.
- Tumia < na > buttons to set the watering duration (from 1 to 360 minutes).
- Bonyeza OK kuthibitisha.
4.4. Set Watering Frequency (How Often)
- Washa piga kuwa MARA ngapi.
- Tumia < na > buttons to set the watering frequency (from every hour up to every 7th day).
- Bonyeza OK kuthibitisha.
4.5. Uendeshaji wa Mwongozo
To water manually without affecting your programmed schedule:
- Washa piga kuwa AUTO/MONGOZO.
- Bonyeza kwa MWONGOZO kitufe.
- Tumia < na > vifungo vya kuweka muda unaotakiwa wa kumwagilia kwa mikono.
- Bonyeza OK kuanza kumwagilia kwa mikono.
- To stop manual watering, press the MWONGOZO button again or turn the dial to IMEZIMWA.
4.6. Kazi ya Kuchelewa kwa Mvua
Kusitisha kwa muda ratiba yako ya kumwagilia kutokana na mvua au sababu nyingine:
- Washa piga kuwa AUTO/MONGOZO.
- Bonyeza na ushikilie KUCHELEWA KWA MVUA button (often integrated with AUTO/MANUAL or a dedicated button).
- Tumia < na > buttons to select the delay duration (1 to 7 days).
- Bonyeza OK to activate the rain delay. The timer will resume its programmed schedule after the delay period.
5. Matengenezo
5.1. Kubadilisha Betri
It is recommended to replace the batteries annually, or when the low battery indicator appears on the display, to ensure continuous operation. Refer to section 3.1 for battery installation steps.
5.2. Uhifadhi wa Majira ya baridi
Before the first frost, remove the timer from the faucet. Drain any water from the timer and store it indoors in a dry, protected location. Freezing temperatures can damage the internal components of the timer.
6. Utatuzi wa shida
| Tatizo | Sababu inayowezekana | Suluhisho |
|---|---|---|
| Timer does not turn on or display is blank. | Betri zilizokufa au zilizosakinishwa vibaya. | Replace batteries with fresh AA alkaline batteries, ensuring correct polarity. |
| Water does not flow at scheduled time. | Faucet is off; rain delay is active; incorrect programming; low water pressure. | Ensure faucet is fully open. Check if rain delay is active. Verify programming settings (start time, duration, frequency). Check water pressure. |
| Timer does not shut off. | Internal valve malfunction; low battery. | Replace batteries. If problem persists, the unit may require replacement. |
| Water leaks from faucet connection. | Loose connection; worn washer. | Ensure connection is hand-tight. Check and replace the rubber washer inside the timer's inlet if it is worn or missing. |
| Timer resets or loses program. | Low batteries; power interruption. | Replace batteries. Reprogram the timer. |
7. Vipimo
- Mfano: 24621
- Chapa: Obiti
- Nyenzo: Plastiki
- Rangi: Kijivu
- Vipimo vya Bidhaa: 3"D x 2"W x 4"H
- Uzito wa Kipengee: Pauni 1.2
- Chanzo cha Nguvu: 2 x AA Betri za Alkali (hazijajumuishwa)
- Idadi ya Mipangilio: 3 (Start Time, How Long, How Often)
- Muda wa Kumwagilia: Dakika 1 hadi 360
- Mzunguko wa Kumwagilia: Every hour up to every 7th day
- Chaguzi za Kuchelewa kwa Mvua: Siku 1 hadi 7
- UPC: 046878246218
Picha ya 7.1: Diagram showing the approximate dimensions of the timer: 3 inches deep, 2 inches wide, and 4 inches high.
8. Udhamini na Msaada
Orbit products are designed for durability and performance. For specific warranty information or technical support, please refer to the official Orbit webtovuti au wasiliana na huduma kwa wateja wao moja kwa moja. Hifadhi risiti yako ya ununuzi kwa madai ya udhamini.
