Utangulizi
Thank you for choosing the OldShark Dash Cam. This 1080P Full HD dashboard camera is designed to provide reliable and high-quality video recording of your journeys, enhancing driving safety and providing crucial evidence in case of incidents. Equipped with a 3-inch display, 170° wide-angle lens, G-Sensor, and loop recording, it's an essential companion for every driver.
Please read this manual thoroughly before operating the device to ensure proper usage and to maximize its performance and lifespan.
Yaliyomo kwenye Kifurushi
Baada ya kufungua, tafadhali hakikisha kwamba vitu vyote vifuatavyo vimejumuishwa kwenye kifurushi chako:
- OldShark Dash Cam Unit
- Chaja ya Gari
- Mlima wa kuvuta
- 32GB Micro SD Kadi
- USB Data Cable
- Mwongozo wa Mtumiaji (hati hii)
Image: All components included in the OldShark Dash Cam package, neatly laid out.
Vipengele vya Bidhaa
- Ultra HD Video Recording: Captures clear 1080P Full HD video, ensuring detailed footage even in challenging light conditions.
- Lenzi ya Pembe Pana Zaidi ya 170°: Hutoa uwanja mpana wa view, minimizing blind spots and capturing more of the road.
- Kihisi G kilichojengewa ndani: Automatically detects sudden impacts or collisions and locks the current video footage to prevent overwriting, serving as crucial accident evidence.
- Kurekodi kitanzi bila mshono: Hubadilisha foo ya zamani zaidi iliyofunguliwatage when the memory card is full, ensuring continuous recording without manual intervention.
- Kichunguzi cha Maegesho cha Saa 24: Records short video clips when vibrations are detected while the vehicle is parked, offering surveillance even when you're away.
- Super Night Vision: Equipped with F1.6 large aperture, WDR (Wide Dynamic Range), and HDR (High Dynamic Range) technology for enhanced clarity in low-light conditions.
- Ufungaji Rahisi: Simple plug-and-play setup with included suction mount and car charger.
Image: Visual representation of the dash cam's 1080P Full HD video capabilities and display features.
Image: The G-Sensor feature, which automatically locks video footage during an impact to secure accident evidence.
Image: The 24-Hour Parking Monitor feature, which activates recording upon detecting vibrations while parked.
Image: The Super Night Vision capability, demonstrating improved low-light performance with its F1.6 aperture.
Image: The 170° wide-angle lens providing a broad view, pamoja na examples of recorded footage during day and night.
Mwongozo wa Kuweka
1. Kuweka Dash Cam
- Clean the windshield area where you intend to mount the dash cam. Ensure it is free of dust and grease.
- Ambatisha kifaa cha kufyonza kwenye kifaa cha kamera ya dashibodi.
- Press the suction cup firmly against the windshield and flip the lever to secure it. Position the camera to ensure a clear view of the road without obstructing your driving vision.
2. Kuingiza Kadi ndogo ya SD
- Locate the Micro SD card slot on the side of the dash cam.
- Insert the provided 32GB Micro SD card into the slot until it clicks into place. Ensure the card is inserted correctly with the gold contacts facing the back of the camera.
- For optimal performance, it is recommended to format the SD card within the dash cam's settings before first use and periodically thereafter.
3. Kuwasha
- Connect the car charger to the dash cam's power input port.
- Chomeka upande wa pili wa chaja ya gari kwenye soketi nyepesi ya sigara ya gari lako.
- The dash cam will automatically power on and begin recording when your vehicle's ignition is turned on. It will also power off automatically when the ignition is turned off.
Image: The OldShark Dash Cam, showing its compact design, the included suction mount for windshield attachment, and the 32GB Micro SD card for storage.
Maagizo ya Uendeshaji
Operesheni ya Msingi
- Washa/Zima: The camera powers on/off automatically with the car ignition. You can also manually power it on/off by pressing and holding the Power button.
- Kurekodi: Once powered on, the dash cam automatically starts loop recording. A red flashing dot or similar indicator on the screen confirms recording is active.
- Acha Kurekodi: Press the OK button to stop recording. Press it again to resume.
- Kubadilisha Modi: Use the Mode button to switch between Video Recording, Still Photo, and Playback modes.
- Uchezaji: In Playback mode, use the Up/Down buttons to navigate through recorded files. Press OK to play a selected video.
Urambazaji wa Menyu
- Press the Menu button to access settings.
- Use the Up/Down buttons to scroll through menu options.
- Press OK to select an option or confirm a setting.
- Press Menu again to exit the menu.
Kazi Muhimu
- Kurekodi Kitanzi: Set the duration for video segments (e.g., 1, 3, 5 minutes). When the card is full, the oldest unlocked file itaandikwa upya.
- Unyeti wa G-Sensor: Adjust the sensitivity of the G-Sensor (Low, Medium, High). A higher sensitivity means the camera will lock footage more easily upon detecting bumps or impacts.
- Ufuatiliaji wa Maegesho: Enable this feature to allow the dash cam to automatically record a short video when it detects a vibration while the car is parked and turned off.
- Utambuzi wa Mwendo: When enabled, the camera will start recording automatically if it detects movement in front of the lens while parked.
- Tarehe/Saa Stamp: Ensure the correct date and time are set in the menu for accurate timestamps kwenye rekodi zako.
Matengenezo
- Kusafisha: Tumia kitambaa laini na kikavu kusafisha lenzi ya kamera na skrini. Epuka kutumia visafishaji au viyeyusho vyenye kukwaruza.
- Utunzaji wa Kadi ya SD: Regularly format the Micro SD card (at least once a month) within the dash cam's settings to maintain optimal recording performance and prevent data corruption. Use only high-quality Class 10 or higher Micro SD cards.
- Halijoto: Avoid exposing the dash cam to extreme temperatures (very hot or very cold) for extended periods, as this can affect battery life and component integrity.
- Sasisho za Firmware: Check the official OldShark website periodically for any available firmware updates to ensure your dash cam has the latest features and bug fixes.
Kutatua matatizo
| Tatizo | Suluhisho |
|---|---|
| Dashi cam haiwashi. | Ensure the car charger is securely connected to both the dash cam and the vehicle's cigarette lighter. Check if the vehicle's cigarette lighter is receiving power. Try a different power source if available. |
| Kurekodi huacha bila kutarajia. | Check if the Micro SD card is full. Format the SD card. Ensure you are using a Class 10 or higher SD card. Reduce G-Sensor sensitivity if it's triggering too often. |
| Video footage haina ukungu au haijulikani wazi. | Clean the camera lens and your car's windshield. Ensure the protective film has been removed from the lens. Check video resolution settings. |
| Dash cam freezes or becomes unresponsive. | Press the reset button (if available, usually a small pinhole) or disconnect and reconnect the power. Format the Micro SD card. |
| Date and time are incorrect. | Go to the system settings menu and manually set the correct date and time. Save the settings. |
Vipimo
| Kipengele | Maelezo |
|---|---|
| Jina la Mfano | GS505 |
| Nambari ya Mfano wa Kipengee | A1OS-GS505-T032 |
| Azimio la Kukamata Video | 1080p Kamili HD |
| Pembe ya Lenzi | 170° Upana wa Pembe |
| Ukubwa wa Kuonyesha | Inchi 3 |
| Vipengele Maalum | G-Sensor, Loop Recording, Parking Guard, Motion Detection, Auto On/Off, Time Stamp, Screensaver, Night Vision (F1.6 Aperture) |
| Teknolojia ya Uunganisho | USB |
| Aina ya Kuweka | Mlima wa kuvuta |
| Vipimo vya Bidhaa | Inchi 3.46 x 1 x 0.59 |
| Uzito wa Kipengee | 4.4 wakia |
| Mtengenezaji | Old Shark |
Taarifa ya Udhamini
OldShark products are manufactured with high-quality standards. For specific warranty terms and conditions, please refer to the warranty card included in your product packaging or contact OldShark customer support. The warranty typically covers manufacturing defects for a specified period from the date of purchase.
Tafadhali hifadhi risiti yako ya ununuzi kama dhibitisho la ununuzi kwa madai yoyote ya udhamini.
Usaidizi wa Wateja
If you encounter any issues or have questions regarding your OldShark Dash Cam that are not covered in this manual, please do not hesitate to contact our customer support team.
For the most up-to-date contact information and support resources, please visit the official OldShark store on Amazon or their official webtovuti.
Rasilimali za Mtandaoni:
- OldShark Amazon Store: Tembelea Duka
