1. Utangulizi
This manual provides essential instructions for the proper setup, programming, operation, and maintenance of your Mopar OEM 3-Button Keyless Entry Remote Key Fob. Please read this manual thoroughly before attempting any procedures to ensure correct functionality and vehicle compatibility.
Figure 1: Mopar OEM 3-Button Keyless Entry Remote Key Fob
The Mopar OEM 3-Button Keyless Entry Remote Key Fob is designed to provide convenient access and ignition control for compatible RAM Truck models. This device is not self-programmable and requires professional assistance for programming.
2. Utangamano
This key fob is compatible with the following RAM Truck models, provided the FCC ID and Part Number match your vehicle's original remote:
- Kitambulisho cha FCC: GQ4-53T
- Nambari ya Sehemu: 56046953AE, 56046953AC
Miundo Sambamba ya Magari:
- RAM Truck 1500 (2013-2022)
- RAM Truck 2500 (2013-2022)
- RAM Truck 3500 (2013-2022)
Kumbuka Muhimu: This remote does not have the smart key Proximity feature and will not work with vehicles that utilize this feature. The key must be inserted into the ignition to operate the vehicle.
Figure 2: Compatibility details for Keyless Entry Remotes
3. Yaliyomo kwenye Kifurushi
Kifurushi chako kinapaswa kuwa na vitu vifuatavyo:
- OEM 3-Button Keyless Entry Remote Key Fob (with pre-installed Duracell battery)
- Uncut Remote Head Key Blade
4. Kuweka
4.1. Key Blade Preparation
The included key blade is uncut. It must be cut by a professional locksmith or dealership to match your vehicle's ignition. This physical key is essential for starting the vehicle and for emergency entry.
4.2. Usakinishaji wa Betri (Imesakinishwa awali)
Your key fob comes with a brand new Duracell battery pre-installed for immediate use. No initial battery installation is required.
Video 1: Disassembly and assembly of a Dodge Ram key fob, demonstrating internal components and key blade insertion.
5. Maagizo ya Kuandaa
The key fob is not self-programmable. It requires programming by a professional locksmith or an authorized dealership. This process typically involves specialized equipment to link the new key fob to your vehicle's immobilizer system.
Figure 3: Professional programming is required for this key fob.
5.1. Professional Programming Process Overview
When taking your key fob to a professional, they will typically perform the following steps:
- The technician will connect a diagnostic tool to your vehicle's OBD-II port.
- Using the diagnostic tool, they will access the vehicle's computer system to initiate the key programming sequence.
- Your new key fob will be registered with the vehicle's immobilizer system.
- The physical key blade will be cut to match your vehicle's ignition.
- The technician will test all functions of the new key fob (lock, unlock, panic, ignition) to ensure proper operation.
Video 2: Demonstration of a key fob programming tool for Dodge Ram 2013-2017 models.
6. Maagizo ya Uendeshaji
Once programmed, your key fob will perform the following functions:
- Kitufe cha Kufunga (): Bonyeza mara moja ili kufunga milango yote ya gari.
- Kitufe cha Kufungua (): Press once to unlock the driver's door. Press twice within five seconds to unlock all vehicle doors.
- Panic Button (Red 'PANIC'): Press and hold for approximately three seconds to activate the vehicle's alarm system. Press again to deactivate.
- Kuwasha: Insert the cut key blade into the ignition and turn to start the vehicle.
7. Matengenezo
7.1. Kubadilisha Betri
The key fob uses a 3V Lithium Cell battery (e.g., CR2032). When the remote's range decreases or it stops responding, the battery may need replacement. Refer to Video 1 for guidance on disassembling the key fob to access the battery compartment.
- Carefully separate the two halves of the key fob casing.
- Remove the old battery, noting its orientation (+/-).
- Insert a new 3V Lithium Cell battery (CR2032) with the correct polarity.
- Reassemble the key fob casing salama.
8. Utatuzi wa shida
- Kidhibiti cha Mbali hakijibu: Ensure the battery is correctly installed and has sufficient charge. If the issue persists, the key fob may need to be reprogrammed by a professional.
- Gari halijaanza: Verify the key blade is properly cut and inserted into the ignition. If the vehicle still does not start, there may be an issue with the key fob's transponder chip or the vehicle's immobilizer system, requiring professional diagnosis.
- Utendaji wa Muda: This could indicate a low battery or interference. Try replacing the battery. If the problem continues, consult a professional.
9. Vipimo
| Kipengele | Maelezo |
|---|---|
| Chapa | Mopar |
| Nambari ya Mfano | 56046953 |
| Kitambulisho cha FCC | GQ4-53T |
| Nambari ya Sehemu | 56046953AE, 56046953AC |
| Idadi ya Vifungo | 3 (Lock, Unlock, Panic) |
| Aina ya Betri | 3V Lithium Cell (CR2032) |
| Vipimo | Inchi 2.5 x 0.6 x 3.7 |
| Uzito wa Kipengee | 0.798 wakia |
10. Udhamini na Msaada
Bidhaa hii inakuja na a 60-day parts warranty. We ensure every remote and key fob is functioning perfectly before shipment. For any questions or technical assistance, please refer to the contact information provided with your purchase or consult the seller directly.
Figure 4: Customer Service and Technical Support
